Medium-sized split type liquid nitrogen machine

The air enters the air compressor after removing dust and mechanical impurities through the air filter, compressing to the required pressure, and outputting clean compressed air after strict purification treatment of oil, water and dust removal, with the purpose of ensuring the service life of the molecular sieve in the adsorption tower.

There are two adsorption towers with carbon molecular sieves, one tower works while the other tower is decompressed and desorbed. The clean air enters the working adsorption tower, passing through the molecular sieve when oxygen, carbon dioxide and water are adsorbed by it, the gas flowing to the exit end is nitrogen and trace amounts of argon and oxygen. Another tower (desorption tower) so that the adsorbed oxygen, carbon dioxide and water from the molecular sieve pores out of the discharge to the atmosphere. In this way, the two towers take turns to complete the separation of nitrogen and oxygen, continuous output of nitrogen, variable pressure (_bian4 ya1) adsorption nitrogen purity of 95%-99.9%, if you need a higher purity of nitrogen need to increase the nitrogen purification equipment. Variable pressure adsorption nitrogen machine output of 95%-99.9% nitrogen into the nitrogen purification equipment, while adding the appropriate amount of hydrogen through a flow meter, in the purification equipment in the oxygen removal tower hydrogen and nitrogen in the trace oxygen catalytic reaction to remove oxygen and then cooled by the water condenser, vapor separator to remove water, and then through the dryer depth drying removal.
